Chainway H100

Physical Characteristics
Dimensions 154.8*73.8*14.5mm/6.09*2.91*0.57in
Weight 227g/8.0oz
Display 5.0 inch high-resolution (1920*1080) LTPS LCD screen
Touch Panel Multi-point capacitive touch panel, supporting operation with
gloves and wet hands
Power Main battery: Li-ion, rechargeable, built-in 4000mAh
Expansion Slot 2 Micro SIM slots, 1 TF slot
Interfaces USB 2.0, Type-C
Audio Speaker, microphone; supporting voice calls
Keypad 1 power switch, 2 scan keys, 1 multifunctional key, 1 Home button, 1 TP Return button, 1 TP Menu button
Sensors Gravity sensor, Light Sensor, Proximity Sensor, Vibration Motor
Pupil Lamp Yellow LED light

User Environment
Operating Temp. -4°F to 122°F / -20°C to 50°C
Storage Temp. -40°F to 158°F / -40°C to 70°C
Humidity 5% RH - 95% RH non condensing
Drop Specification Multiple 1.5m/4.9ft drops to the concrete across the operating temperature range
Tumble Specification 1000 x 0.5m/1.64ft falls at room temperature
Sealing IP65
ESD ±8KV air discharge, ±4KV conductive discharge

Performance
CPU Cortex-A53 1.3GHz Quad-core
RAM+ROM 2GB+16GB
Expansion Supports up to 32 GB Micro SD card

Developing Environment
Operating System Android 6.0
SDK Chainway Software Development Kit
Language Java
Tool Eclipse/Android Studio

Communication
WLAN IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna
WWAN 2G: 900/1800MHz
3G: 900/1900/2000/2100MHz
4G:TDD-LTE: B38, B39, B40, B41
    FDD-LTE: B1, B3, B5
Bluetooth Bluetooth 4.0, BLE
GNSS GPS/AGPS, GLONASS, BeiDou; internal antenna

Barcode Scanning
Scan engine Zebra SE4710
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc
2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Camera
Camera 13MP autofocus camera with flash

NFC
Frequency 13.56MHz
Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips M1 card (S50, S70), CPU card, NFC tags, etc.
Range 2-4cm

Fingerprint
Module FPS958E
Sensor Type Capacitive Sensor
Pixel Array 56*56
