MECHANICAL
|
|
Dimensions (HxWxD)
322.6 mm x 320.5 mm x 472.4 mm
(12.7 in x 12.6 in x 18.6 in)
|
|
Weight
20.5 kg (45 lbs)
|
|
Construction
Solid aluminum die-cast frame with a metal cover and large clear side window to easily monitor media supply levels.
|
|
ENVIRONMENTAL
|
|
Operating Temperature:
0°C to 40°C (32°F to 104°F)
|
|
OPTIONS
|
|
Two USB Host
SDIO
Cast Peel Present and Internal Rewind
Cutter (10 mil)
Ethernet-Wired LAN 10/100
Wi-Fi a/b/g/n/ac
GPIO Applicator Interface Card
|
|
POWER SOURCE
|
|
Electrical
Auto-sensing 90–132V AC or 180–264V AC @ 47–63 Hz
|
|
ACCESSORIES
|
|
External Rewinder
Media Tray for Cutter
|
|
PRINT TECHNOLOGY
|
|
Printer Type
Direct thermal, optional thermal transfer
|
|
Printer Speed/Resolution
I-4212e: 304 mms (12 ips), 8 mmps (203 dpi)
I-4310: 254 mms (10 ips), 12 mmps (300 dpi)
I-4606: 152 mms (6 ips), 24 mmps (600 dpi)
|
|
SOFTWARE/FIRMWARE
|
|
NETira™ CT
Complete printer setup utility
|
|
NETira LD
Label design software Embedded network web pages
|
|
Drivers
Microsoft® Windows® NT, Windows XP, Windows Vista
|
|
Firmware
Auto Detect – DPL, ZSim2 (Zebra), PL-I (Intermec)
|
|
MEDIA
|
|
For optimum print quality and printer performance, use certified Honeywell media supplies.
|
|
Media Types
Roll-fed: 203.2 mm (8.0 in) O.D. on a 38.1 mm to 76.2 mm (1.5 in to 3.0 in) core
|
|
Fan-Fold Stock
Accepted from rear of printer
Die-cut or continuous labels
Perforated or continuous tag/ticket stock
|
|
Maximum Print Width
I-4212e: 104.1 mm (4.10 in)
I-4310: 105.7 mm (4.16 in)
I-4606: 105.7 mm (4.16 in)
|
|
Minimum Media Length
Tear-off and rewind modes: 6.4 mm (0.25 in)
Peel and cutter modes: 25.4 mm (1.0 in)
|
|
Media Width Range
25.4 mm to 118.1 mm (1.0 in to 4.7 in)
|
|
Media Thickness Range
0.06 mm to 0.25 mm (0.0025 in to 0.01 in)
|
|
Media Sensing
“See through” for liner-backed die-cut labels and tags, reflective sensor for black- mark label media
|
|
Label Backfeed
For use with optional cutter
|
|
Ribbon Width Range
25.4 mm to 114.3 mm (1.0 in to 4.5 in)
|
|
Ribbon Core
25.4 mm (1.0 in)
|
|
Ribbon Length
600 m (1,968 ft)
Coated-side-in or coated-side-out
|
|
AGENCY APPROVAL
|
|
Contact your Honeywell sales representative forthe most recent list of agency approvals.
|
|
COMMUNICATION
|
|
Communication Ports (Standard)
Serial RS232, USB 2.0, Parallel bi-directional
|
|
Communication Ports (Optional)
10/100 BaseT Ethernet, 2 USB host & SDIO, W-LAN, 802.11 a/b/g/n/ac, GPIO applicator interface card
|
|
BARCODES/FONTS/GRAPHICS
|
|
Barcodes:
Linear Symbologies
Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5, Industrial 2 of 5, Std 2 of 5, Code 11, Code 93, Code 128, EAN-8, EAN-13, HIBC, Codabar, Plessey, UPC 2 and 5-Digit Addendums, Postnet, UCC/EAN Code 128, Telepen, Planetcode, FIM, USPS-4 State
|
|
2D Symbologies
MaxiCode, PDF417, USD-8, Datamatrix, QR Code, Codablock, Code 16k, Aztec, TLC 39, Micro PDF417, GS1 Databar
|
|
Resident Fonts
Ten alphanumeric fonts from 2.5- to 23-point size, including OCR-A, OCR-B, CG Triumvirate smooth font from AGFA
|
|
Scalable Fonts
CG Triumvirate Bold Condensed, CG Triumvirate, and CG Times with Cyrillic, Greek, Arabic, and Hebrew character support
|
|
Downloadable Font Types
TrueType, Bitmap
|
|
Character Set
More than 50 resident character sets Unicode/UTF8 support
|
|
Font Expansion
All fonts expandable vertically and horizontally up to 24x
|
|
Font Rotation
Fonts and graphics can be printed in four directions: 0°, 90°, 180°, and 270°
|
|
Graphics Supported
.pcx, .bmp, and .img format files
|
|
Reversible Field/Mirror Image
Any font or graphic field can be printed as a normal or reverse image
|
|
WARRANTY
|
|
Standard Warranty
Covers platen roller, printhead, and installed options when used with approved supplies
Printer: 1 year
Printhead: 1 year or 25,400,000 mm (1,000,000 in), whichever comes first
|
|
Extended Warranty
Contact your Honeywell sales representative for extended warranty options available through Honeywell Repair Services.
|
